Specifications
- Factory set at 50 psi adjustable to 80 psi
- 3 gallon reservoir
- 115 or 230 VAC / 1 ph-50/60Hz
- 5.6 / 2.8 amp:60 Hz
- 12,000 BTU
- Dimensions: 18″L x 14″W x 9″H
- Net weight: 37 lbs / 17 kg
- Foam packed for UPS shipment
PCIIG: Rotary GEAR Pump
- 1.8 gpm at 50 psi
- Built in by-pass to tank
- Rebuildable Pump (Repair Kit Product No. P3001)
PCIIV: Rotary VANE Pump
1.7 gpm at 50 psi
System Features
- Plastic water tank eliminates coolant contamination due to electrolysis or chemical reactions.
- All units are plumbed with copper tubing and reinforced hose.
- New extended life pump features a direct drive power system reducing maintenance and vibration.
- No external plumbing is required because of closed loop water system.
- Self priming pump
- Easy change pump
- Strong rigid construction designed to support power unit.
- Compact design
